RCF ART 745-A MK5
Localstores
More
Large selection
From pick to amp, from stick to kit: we are your one-stop shop for everything you need!
The ART 745-A MK5 is the flagship of this speaker family. The neodymium compression driver with 4-inch voice coil and titanium dome ensures assertiveness and unique voice transparency. The 15-inch neodymium woofer offers precise, controlled bass reproduction with its extremely linear frequency response . All sound transducers are produced using the latest manufacturing technology. The 1400 watt amplifier is controlled by a digital signal processor that controls crossover, EQ, phase control, soft limiting and speaker protection.
- 133 dB maximum sound pressure level
- 1400 watts peak power
- Constant directivity horn with large cover of 90° x 60°
- Innovative digital signal processing
- Neodymium compression driver with 4-inch voice coil and titanium dome
- 15-inch neodymium woofer
- FiRPHASE technology
- XBOOST Low Frequency Enhancer
- frequency response: 45 Hz ÷ 20000 Hz
- Max SPL @ 1m: 133dB
- Horizontal radiation angle: 90°
- Vertical radiation angle: 60°
- Compression driver: 1 x 1.0'' neo
- Woofer: 15''
- Input signal: bal/unbal
- Input jacks: XLR, Jack
- output connections: XLR
- Input sensitivity: -2 dBu/+4 dBu
- Mic input sensitivity: -32 dBu
- Crossover frequency: 650
- Protection circuits: Thermal, RMS
- limiter: Soft limiter
- control: Volume, Boost, MIC/Line
- total output: 1400W peak
- RF range: 400W peak
- depth frequencies: 1000W peak
- cooling: Convection
- Connections: VDE
- Safety agency: CE compliant
- hardware: 2 x M10
- handles: 1x top, 1x right, 1x left
- Pole Mount/Cap: Yes
- color / finish: Black
- height: 708 mm / 27.87 inches
- width: 437 mm / 17.2 inches
- depth: 389 mm / 15.31 inches
- weight: 18.8 kg / 43.21 lbs
- Bluetooth-Streaming: no
- Color/ Finish: Black
- Controls: Gain control, EQ-Boost on/off, Mic/Line selector, power on/off
- Dimensions Top: 708 x 437 x 389 mm (HxWxD)
- EQ: EQ selector flat/boost
- Flyability: Yes
- Frequency range: 45 Hz - 20 kHz
- HF-/(MF) driver: 1"
- Housing Top: Plastic
- Includes: Speaker, Power Cord
- Inputs: XLR, 6.3 mm Jack
- LF-Driver: 1x 15" (38,10 cm)
- Low-Cut: no
- Mic-preamp: 1x Mic-In
- Mixer Included: no
- Outputs: XLR (Thru)
- Pole flange: 35 mm Flange
- Power amp output: 1400 W
- Presets: no
- Radiation Angle: 90° x 60°
- Simultaneously usable inputs: 1 ch
- Subcategory: Fullrange speaker
- Weight Top: 18,8 kg
- max. SPL ( 1 W/1 m): 129 dB
RCF has been setting standards in the audio industry since 1949 and has established itself as one of the leading suppliers of professional sound reinforcement systems. The brand combines decades of experience with innovative technologies to create audio solutions that are used in venues, studios and installations worldwide. Whether at concerts, festivals or in theaters - RCF products are characterized by their reliability, robust workmanship and exceptional sound quality. Thanks to its advanced technology, RCF delivers systems that impress both musicians and sound engineers and enrich events of any size with crystal-clear sound.
Their product range extends from compact loudspeakers to complex PA systems that ensure perfect sound distribution. Of particular note is RCF's commitment to continuous research and development to remain at the forefront of audio-visual innovation. From the invention of the first Italian PA system to today's high-tech solutions, RCF has shaped the global audio market with an uncompromising focus on quality and performance.
